Axial Fans
Based on our nearly 30 years of experience in fan & blower manufacturing industry, Yilida's axial fans feature proven performance, high efficiency and low noise level. Given the reliability of their design, these axial fans can operate smoothly and efficiently in various applications including air conditioning (HVAC), ventilation, cooling and industrial processing. We are able to offer a vast range of axial fans that differ in design and functionality such as EC axial fan and cooling fan, and they are selectable according to air flow up to 100,000m³/h.
- Axial Fan, C6.C7 Series
- Usage: screw compressors, general ventilation applications
- Impeller diameter: 350-900mm
- Air flow: 1800-30000m³/h
- Operating temperature: -20℃-80℃
- Drive method: internal rotor motor
- Axial Fan, D Series
- Usage: air conditioners, screw compressors, general ventilation applications
- Impeller diameter: 630-900mm
- Air flow: 5000-30000m³/h
- Operating temperature: -20℃-80℃
- Drive method: internal rotor motor
- Axial Fan, E Series
- Usage: residential air conditioners, home central air conditioners
- Impeller diameter: 120-590mm
- Air flow: 300-8500m³/h
- Operating temperature: -10℃-40℃
- Drive method: internal rotor motor
- Axial Fan, F Series
- Usage: air compressors, portable ventilation devices
- Impeller diameter: 350-1800mm
- Air flow: 1250-100000m³/h
- Operating temperature: -10℃-80℃
- Drive method: internal rotor motor
- Axial Fan, G Series
- Usage: air conditioners, heat pumps, screw compressors, general ventilation applications
- Impeller diameter: 450-900mm
- Air flow: 2500-30000m³/h
- Operating temperature: -10℃-80℃
- Drive method: internal rotor motor
- Axial Fan, J Series
- Usage: air conditioners, heat pumps and other general ventilation devices requiring low air resistance
- Impeller diameter: 560-800mm
- Air flow: 4000-20000m³/h
- Operating temperature: -10℃-80℃
- Drive method: internal rotor motor
- EC Axial Fan, RMSWF Series
- Usage: refrigerators and freezers
- Impeller diameter: 300-900mm
- Air flow: 1000-33000m³/h
- Pressure: 0-240Pa
- Motor power: 141W-1912W
- Communication: VSP/PWM/485
- Insulation class: F
- Operating temperature: -40℃-60℃
- EC Axial Fan with External Rotor
- Usage: air conditioning, supply and exhaust ventilation systems
- Impeller diameter: 400-600mm
- Air flow: 1800-13500m³/h
- Pressure: up to 200Pa
- Drive method: direct drive
- Installation: suitable for both vertical and horizontal mounting
- EC Axial Fan with External Rotor (Cooling Fan)
- Usage: air conditioning, supply and exhaust ventilation systems
- Impeller diameter: 400-600mm
- Air flow: 1800-13500m³/h
- Pressure: up to 200Pa
- Drive method: direct drive
- Installation: suitable for both vertical and horizontal mounting
- Axial Fan with External Rotor (Cooling Fan), LF2 Series
- Usage: air conditioning, supply and exhaust ventilation systems
- Impeller diameter: 500-630mm
- Air flow: 1800-13500m³/h
- Pressure: up to 200Pa
- Drive method: direct drive
- Installation: suitable for both vertical and horizontal mounting
- EC Backward Curved Axial Fan with External Rotor
- Usage: residential air conditioners, home central air conditioners
- Impeller diameter: 250-910mm
- Air flow: 1500-30000m³/h
- Operating temperature: -10℃-40℃
- Drive method: internal rotor motor
- Fan Motor, YSF/YDF Series
- Protection class: IP54, IP55
- Insulation class: F
- Output power: 40-40000W
- Number of poles: 2, 4, 6, 8
- Operating conditions
- Ambient temperature: -10℃-80℃
- Relative humidity: ≤95%
- Altitude: ≤1000m
About YILIDA
Yilida is a listed company that has been delivering custom fan solutions to global HVAC system market for nearly 30 years. Our longevity in the ventilation and air conditioning industry is based on the top quality of our ventilation fans that have been approved by AMCA, and global service network which can quickly response to worldwide customers who are looking for commercial fans or industrial blowers. Yilida has 8 fan production bases to manufacture a broad range of centrifugal fans and axial fans. Whether you are looking for general ventilation fans, smoke extract fans, inline duct fans, roof mounted fans or industrial process fans, Yilida can produce the air moving products that are precisely oriented to your applications of ventilation, smoke extraction, air conditioning, and more.
